Tiny JCB 514-40 Loadall packs huge cab
JCB is introducing the 514-40, its smallest Loadall telescopic handler to date, with a cab height of just 1.8m and a width of 1.56m. However, the compact machine benefits from the largest operator’s cab in the class, sharing its core DNA with the world’s number one telehandler range.
The telehandler is powered by a low maintenance 18.4kW (24.7hp) diesel engine that meets the EU Stage 5 emissions standard without the need for a complex Diesel Particulate Filter (DPF) or any diesel exhaust fluid, reducing operating costs for customers and simplifying operation.
This 3-cylinder, 1.1-litre engine, which boasts 66.9Nm of torque, drives through a proven Bosch hydrostatic transmission to a 2-speed Linde motor, delivering a maximum travel speed of 15km/h. There's also permanent 4-wheel drive and 4-wheel steering.
The maximum lift capacity is 1,400kg, while maximum lift height is set at 4m, making this an ideal machine for numerous industry sectors, reckons JCB. Lift capacity at full reach is set at 525kg. With an unladen weight of 2,695kg, the machine boasts a 17% higher power-to-weight ratio than the previous 516-40 Loadall.
However, the 514-40 can be transported on a lightweight 3.5-tonne trailer behind a 4x4 or a light commercial vehicle, making it easier, quicker and less expensive to deliver to site for a rental company, a contractor or a weekend DIYer.
The full width operator’s cab is 20% larger than the previous 516-40 and a full 200mm wider than competitive models. This provides the operator with a comfortable working environment and the extensive glazing delivers excellent visibility to all four corners. The cab will be instantly familiar to operators of other Loadall models, with JCB’s intuitive ergonomic controls making the 514-40 one of the easiest machines to operate.
Standard features include a 50mm tow ball with 7-pin electrics, reversing alarm, road lights, the patented JCB load control system and JCB’s LiveLink Lite telematic system. Options include an LED work light package, amber and green beacons with an orange seat belt, which can all be protected by JCB’s immobiliser Key Pad.
The 514-40 boasts a new lightweight tool carrier and is capable of working with floating forks or a 0.41m3 bucket. Double-acting auxiliary hydraulics make it possible to operate with a range of JCB attachments, increasing the versatility of this compact machine. Customers can also choose between a range of industrial and turf-compatible tyres.
